GQ22Q
Yatian
Dual Motor System: Equipped with two 48V 5KW high-efficiency permanent magnet synchronous motors, delivering robust power and smooth acceleration. Switch between front-wheel, rear-wheel, and all-wheel drive modes for optimal traction on any terrain.
Long-Lasting Battery: Powered by 6×8V high-capacity deep-cycle traction batteries, ensuring an extended range of up to 80km on a single charge.
Advanced Charging: Comes with a fully automatic high-frequency pulse charger (110V/220V input, 48V 25A output), making charging both convenient and efficient.
Smooth Driving Control: The CMOS stepless speed control system with automatic rollback prevention ensures seamless transitions on various terrains. Features include downhill speed limiting and personalized driving programs for added safety and flexibility.
Sturdy Body & Chassis: Constructed with high-strength steel tubing and coated with rust-resistant electrophoretic paint, the lightweight injection-molded body ensures durability and longevity while maintaining a sleek, modern look.
Independent Suspension: The vehicle features a MacPherson independent suspension system on both the front and rear axles, enhancing stability and comfort over bumpy and uneven surfaces.
Efficient Braking System: The dual-circuit hydraulic braking system with disc brakes on all four wheels ensures precise braking control. The vehicle is also equipped with a mechanical handbrake for secure parking on inclines.
Off-Road Tires: Fitted with 23×10.5-12 vacuum radial all-terrain tires, these wide off-road tires provide superior traction and reduce the risk of damage to soft surfaces like grass or mud.
Comfortable Seating: The seats are crafted with high-density polyurethane foam and covered in durable, waterproof leather, offering excellent comfort and support for long drives.
Towing Capabilities: The vehicle comes with a front electric winch for efficient towing and rescue operations, making it ideal for tough off-road tasks.
Weight: 740kg
Dimensions (L×W×H): 3020×1340×2120mm
Wheelbase: 1700mm
Minimum Ground Clearance: 190mm
Seating Capacity: 4 (2+2 configuration)
Maximum Forward Speed: ≤30km/h
Maximum Reverse Speed: 9-13km/h
Climbing Ability: 20%
Minimum Turning Radius: 3900mm
Maximum Noise Level: ≤60dB(A)
Brake Distance: ≤5m
Dual Motor System: Equipped with two 48V 5KW high-efficiency permanent magnet synchronous motors, delivering robust power and smooth acceleration. Switch between front-wheel, rear-wheel, and all-wheel drive modes for optimal traction on any terrain.
Long-Lasting Battery: Powered by 6×8V high-capacity deep-cycle traction batteries, ensuring an extended range of up to 80km on a single charge.
Advanced Charging: Comes with a fully automatic high-frequency pulse charger (110V/220V input, 48V 25A output), making charging both convenient and efficient.
Smooth Driving Control: The CMOS stepless speed control system with automatic rollback prevention ensures seamless transitions on various terrains. Features include downhill speed limiting and personalized driving programs for added safety and flexibility.
Sturdy Body & Chassis: Constructed with high-strength steel tubing and coated with rust-resistant electrophoretic paint, the lightweight injection-molded body ensures durability and longevity while maintaining a sleek, modern look.
Independent Suspension: The vehicle features a MacPherson independent suspension system on both the front and rear axles, enhancing stability and comfort over bumpy and uneven surfaces.
Efficient Braking System: The dual-circuit hydraulic braking system with disc brakes on all four wheels ensures precise braking control. The vehicle is also equipped with a mechanical handbrake for secure parking on inclines.
Off-Road Tires: Fitted with 23×10.5-12 vacuum radial all-terrain tires, these wide off-road tires provide superior traction and reduce the risk of damage to soft surfaces like grass or mud.
Comfortable Seating: The seats are crafted with high-density polyurethane foam and covered in durable, waterproof leather, offering excellent comfort and support for long drives.
Towing Capabilities: The vehicle comes with a front electric winch for efficient towing and rescue operations, making it ideal for tough off-road tasks.
Weight: 740kg
Dimensions (L×W×H): 3020×1340×2120mm
Wheelbase: 1700mm
Minimum Ground Clearance: 190mm
Seating Capacity: 4 (2+2 configuration)
Maximum Forward Speed: ≤30km/h
Maximum Reverse Speed: 9-13km/h
Climbing Ability: 20%
Minimum Turning Radius: 3900mm
Maximum Noise Level: ≤60dB(A)
Brake Distance: ≤5m
