Black LY04A Yatian Manufacturing 1903 : A Retro Instagrammable Antique Car for An Luxurious Getaway Experience at Golf Courses, Luxury Hotels, And Resorts

                                                  Yatian 1903 Electric Antique Car

The Yatian 1903 Electric Antique Car is a meticulously crafted antique vehicle that combines classic designs from the early 20th century with modern design principles.

The entire car features a metal structure and automotive-grade paintwork, ensuring an environmentally friendly and noise-free operation with easy handling, utilizing the latest electric drive system.

This car is suitable for use in hotels, clubs, high-end villa areas, and tourism attractions.

Main Technical Parameters and Performance Indicators:

• Vehicle Weight: 500kg

• Minimum Ground Clearance: 170mm

• Dimensions (L×W×H): 2660×1590×1990mm

• Minimum Braking Distance: ≤5m

• Wheelbase: 1820mm

• Climbing Ability: 20%

• Track Width (Front/Rear): 1330/1380

• Maximum Noise Level: ≤60dB (A)

• Minimum Turning Radius: 3800mm

• Maximum Forward Speed: ≤25km/h

• Seating Capacity: 4 seats

• Maximum Reverse Speed: 9-13km/h

• Maximum Driving Range: ≥80km

• Electrical System

• Motor: 48V5KW high-efficiency high-speed AC motor

• Battery: 6*8V large-capacity deep-cycle traction battery

• Charger: Fully automatic high-frequency efficient pulse charger, input voltage AC 110V/220V, 50Hz; output DC 48V, 25A

• Controller: CMOS stepless speed control system with automatic anti-slip function, downhill speed limit, and customizable program design

• Chassis

• Frame-style, high-strength steel structure with double anti-corrosion treatment (hot-dip zinc and surface paint)

• Rear Axle

• Motor direct-connected overall rear axle with main reduction and differential

• Braking System

• Dual-circuit four-wheel hydraulic brakes (front disc/rear drum), with mechanical parking brake (handbrake)

• Front Suspension System

• Load-bearing multi-leaf spring + cylindrical hydraulic shock absorber

• Rear Suspension System

• Load-bearing multi-leaf spring

• Steering System

• Single-stage gear rack steering system with automatic return function

• Lighting System

• Front headlights, front turn signals, rear combination lights, reverse buzzer, electric horn

• Seating System

• Split seating system designed according to ergonomic principles for comfortable seating

• Tires

• Vacuum radial tires, specification model: 90/90-18

Application Scenarios

1. Golf Courses
   At picturesque golf courses, the Yatian 1903 LY04A electric antique car offers convenient transportation for golfers, allowing them to effortlessly move between holes and enjoy an elegant playing experience.

2. Luxury Hotels
   In high-end hotels, the electric antique car serves as a shuttle for guests, helping them easily reach various facilities such as restaurants, pools, and spas.

3. Resorts
   Within resorts, the Yatian 1903 LY04A can be used for leisure and exploration, allowing guests to leisurely tour the surrounding scenery and enjoy a peaceful and comfortable time.

4. High-End Villa Areas
   In upscale villa neighborhoods, the electric antique car provides a convenient travel option for residents and visitors, perfect for family gatherings, private events, or community activities.

5. Tourist Attractions
   At tourist spots and sightseeing areas, the Yatian 1903 LY04A electric antique car can serve as a guided tour vehicle, helping tourists easily explore and experience local culture and scenery.

6. Weddings and Special Events
   At weddings and special celebrations, the electric antique car can be used as transportation for the newlyweds, adding a romantic and elegant touch to the occasion.

Through these application scenarios, the Yatian 1903 LY04A electric antique car provides a luxurious and convenient travel experience for various occasions.
